EnergyNode Inset angled view
EnergyNode Inset label detail
Outdoor · Luminaire controllers

EnergyNode Inset

✓ Originally engineered for Signify
Request a quote → Download datasheet

DIN-rail BLE DALI lighting controller. Lighting control, simplified.

EnergyNode Inset transfers DALI driver control from the top of the pole to the bottom of the pole cabinet, enabling simple local configuration through a user-friendly app, with no cloud portal required. Originally developed for Signify, it's now also available directly from Remoticom.

5-stepDimming
No cloudRequired
DIN-railMounting
Core features
  • Bluetooth Low Energy configuration
  • DIN-rail controller for lighting poles
  • Works with DALI 2.0 and D4i drivers
  • 230V power supply
  • 5-step dimming profile, timing based on supply on/off cycle
  • Save and copy profiles in the app; reads D4i banks 251, 252, 253
Key benefits
  • Cost-efficient lighting control
  • No cloud portal required
  • Easy local commissioning
  • Fast configuration of individual poles
  • Long service life and quick payback
Typical applications

Where EnergyNode Inset fits.

Outdoor lighting polesRetrofit luminaire controlReplacement of photocell-based solutionsLocal control in switched mains networks

Technical specifications

SupplyMains 220-240V / 50-60Hz
Driver communicationDALI
User device communicationBluetooth (BLE 5.3)
Ingress protectionHousing IP40, connectors IP20
Operating temperature-30°C to +75°C
Dimensions (W×H×L)35 × 40.2 × 89.5 mm
Max. drivers controlled1
ApprobationCE, RED, DALI

Interested in EnergyNode Inset?

Get in touch for full datasheets, pricing or a pilot, or see it in context on the Smart Lighting Outdoor page.
